BAIXAR PES 2011 PARA CELULAR PDFĭownload the GNS3 file and the Cisco TSHOOT Exam Topology PDF and look at them thoroughly. Client1, Client2, FTP Server and Web Server are routers with “IP routing” disabled.Having said that, let me explain the topology a little: It’s a good idea to draw your own network diagram. DSW1 and DSW2 are distribution layer switches.ASW1 and ASW2 are access layer switches with trunks (etherchannels) to DSW1 and DSW2.Client1 and Client2 receive their IP address through DHCP.This turns them into hosts with a default gateway. EIGRP AS 10 has been configured on DSW1, DSW2 and R4.HSRP has been configured to act as a gateway for Client1 and Client2 in VLAN 10. They are connected by using frame-relay point-to-point subinterfaces. R4 is also the DHCP server for VLAN 10.I recommend to take a look at the different DLCI numbers that are in use. You might notice Client1 and Client2 are unable to reach the Web Server.The ISP router advertises network 209.65.200.241 /29 through BGP to AS 65001.R1 has been configured for NAT so all hosts within the private ranges 10.0.0.0/8 and 192.168.0.0/16 are able to access AS 65002.R1 has been configured with BGP AS 65001 and peers with the ISP router that uses BGP AS 65002.DSW1 and DSW2 have been configured to relay DCHP discover messages.
This is because OSPF AREA 34 is blocking the external LSAs (BGP is redistributed into OSPF on R1). It’s a very good idea to start this topology and play around a bit. I will be releasing new labs with troubleshooting tickets that are based on this topology very soon. Have fun! If you have any questions please leave a comment or drop a message in the forum. You need to register to download the GNS3 topology file. Once you are logged in you will find the configuration files right here. I have downloaded the zip file and and installed it. Local working directory /tmp cannot be found for hypervisor 127.0.0.1:7200, use working directory C:\Program Files\GNS3\tmp instead Local working directory /tmp cannot be found for hypervisor 127.0.0.1:7203, use working directory C:\Program Files\GNS3\tmp instead Local IOS image /Data/GNS3/IOS/C3725-AD.BIN cannot be found, use image C:\Program Files\GNS3\Images\c3725-adventerprisek9-mz124-23.image instead => Local working directory /tmp cannot be found for hypervisor 127.0.0.1:7202, use working directory C:\Program Files\GNS3\tmp instead Net file I get a “lost connection”, please see error messages below can you tell me what is the issue? BAIXAR PES 2011 PARA CELULAR ZIP FILE
